Flat TOP/ Smooth Top
All of the mesh knuckles are on the underside, allowing material to move more freely over the screen, while keeping plugging to a minimum.
Top surface of wires all lie in same plane, results in irregular crimped surface on underside. Flat surface improves flow of materials over screen panels by reducing friction.
Double Crimp/Plain Crimp
Woven wire cloth, evenly crimped in warp and weft, providing a rigid construction. The wires are under-crimped and sprung together, thus giving a tight mesh. This is used mainly with lighter wires to ensure tension in a light screen.Lock Crimp
A more modern and versatile crimp style, lock crimp is formed by a straight section of wire weaved with distinct crimp or pockets at wire intersections. Yields a truly tight dimensionally stable mesh.Twilled Weave
Each warp wire and fill wire pass successively over two and under the next adjacent pair of wires, resulting in a more pliable weave.Intercrimp / Intermediate
| Plain hooked | |||||
| Dimension | α | L1 | L2 | R | T（mm） |
| 25°~45° | 31.8mm | — | ≥6mm | — | |
| Remarks | Used for screens of wire diameters greater than 4.0mm or more.Edges are annealed by controlled heating before forming to eliminate cracking and breakage. | ||||
| Reinforced shroud Edge Hook | |||||
| Dimension | α | L1 | L2 | R | T（mm） |
| 30°，45° | 25mm | 31.8mm | 4.7mm | 1.8mm or customize |
|
| Remarks | Hook has a 1.6mm galvanized plate covering the hooks, bent at 45˚or C shaped at 180˚. Used for wire diameters of 1.0mm or more and less than 4.0 mm. | ||||
| Double folded reinforced shroud | |||||
| Dimension | α | L1 | L2 | R | T（mm） |
| 25°~45° | 31.8mm | 31.8mm | 4.7mm | 1.6mm or customize |
|
| Remarks | Hook has a 1.6mm galvanized plate covering the hooks with a double fold bent at 45˚ or C shaped at 180˚. Used on 0.7mm wire down to a 75 mesh. | ||||
| End tension reinforced shroud | |||||
| Dimension | α | L1 | L2 | L3 | T（mm） |
| 180° | 38.1mm (PEP) 63.5m(Powerscreen) |
38.1mm (PEP) 63.5m(Powerscreen) |
17.4mm | — | |
| Remarks | Used for Powerscreen, PEP, Finlay, El Jay, Master­­­skreen and other custom ordered hooks. Good for 1/4" wire and lighter. Other hook dimensions are available on request. | ||||
| Inside Reinforced Formed Edge Hook | |||||
| Dimension | α | L1 | L2 | R | T（mm） |
| 30°~45°，60°，90° | 25mm/31.8mm | 25mm/31.8mm | 6mm | 3mm | |
| Remarks | For wire diameters of 4.0 mm or more and less than 6.0 mm with a metal sheet, and larger for uniform tensioning. A 3mm mild steel angle insert is welded inside the wire hooks, strengthening the screen for uniform tensioning and ease of installation on vibrating equipment. |
||||
| Welded Bent Plate Edge Hook | |||||
| Dimension | α | L1 | L2 | R | T（mm） |
| 30°~45°，90° | 31.8mm | — | 6mm | 3/16"/1/4" | |
| Remarks | for extremely large wire diameter screens and special vibrators.A 3/16" or 1/4" mild steel angle is welded on the screen edge. | ||||
